Filter Sand and Gravel

Highly spherical shape and uniform grading provide our Filter Sand and Gravel with reliable performance

DESCRIPTION

Filter Sand and Gravel are naturally occurring, river washed, glacial deposit products. Their excellent chemical properties – high in silica content and low in soluble calcium, magnesium and iron compounds – meet AWWA-Bl00-96 specifications. Precision sizing and uniform grading to close limits meet the rigid specifications of professional engineers throughout the world.

For over 80 years our Filter Sand and Gravel have been satisfying the requirements of industrial, municipal and residential users. These products have been specified and used nationally and internationally because of their high quality, desirable chemical properties, color, and wide range of precision sizing.

Processing and regular analysis of production are supervised by registered professional engineers.

Our Filter Sand is graded specifically for water filtration plants. It can be used in municipal, industrial or residential applications for sediment filtration.

Our uncrushed Gravel has a highly spherical shape that promotes good flow and even distribution in support beds. Gravel is low in soluble impurities and it will maintain the quality of the treated water, especially in softeners. Three inch layers are recommended in graded support beds.

(back to top)

ADVANTAGES

Our Filter Sand is graded specifically for water filtration plants
Filter Sand can be used in municipal, industrial or residential applications
The spherical shape of uncrushed gravel promotes good flow and even distribution

(back to top)

PHYSICAL PROPERTIES

Filter Sand
Color: Light tan to reddish brown
Density: 100 lbs./cu. ft.
Mesh Size: 18×35*
Effective Size: 0.45-0.55 mm*
Uniform Coefficient: 1.6 or less*
Acid Solubility: 0.3-1.6%
Specific Gravity: 2.65-2.75
* All physical properties and conditions for operation are the same for gravel with the exception of mesh size, effective size and uniformity coefficient.

(back to top)

CONDITIONS FOR OPERATION

Filter Sand
Bed depth: 18-30 in.
Freeboard: % of bed depth (min.)
Backwash flow rate: 15-20 gpm/sq. ft.
Backwash bed expansion: 20% of bed depth
Service flow rate:

Municipal: 1.5-2 gpm/sq. ft.
Industrial: 3 gpm/sq. ft.
Domestic: 5 gpm/sq. ft.

(back to top)

FLOW RATE
Service Flow Pressure Drop and Backwash Bed Expansion charts to be added later. Check back for updates.

(back to top)

ORDER INFORMATION

Part No. A8071
Description: Filter Sand (0.44-0.55 mm)
Cu.Ft./Bag: 1
Wt./Cu.Ft.*: 100 lbs.
Bags/Pallet: 30
Weight/Pallet: 3050 lbs
Pallet Dim: 45″x41″x40″

Part No. A8072-01
Description: #20 Flint
Cu.Ft./Bag: .5
Wt./Cu.Ft.*: 100 lbs.
Bags/Pallet: 40
Weight/Pallet: 2050 lbs.
Pallet Dim: 42″x40″x30″

Part No. A8073
Description: 1/4 x 1/8 Flint
Cu.Ft./Bag: 1
Wt./Cu.Ft.*: 100 lbs.
Bags/Pallet: 30
Weight/Pallet: 3050 lbs.
Pallet Dim: 42″x40″x44″

Part No. A8073-02
Description: 1/4 x 1/8 flint
Cu.Ft./Bag: .5 (50lbs)
Wt./Cu.Ft.*: 100 lbs.
Bags/Pallet: 40
Weight/Pallet: 2050 lbs
Pallet Dim: 42″x40″x30″

Part No. A8074
Description: 1/2 x 1/4 Flint
Cu.Ft./Bag: 1
Wt./Cu.Ft.*: 100 lbs.
Bags/Pallet: 20
Weight/Pallet: 2050 lbs.
Pallet Dim: 42″x40″x28″

Part No. A8075
Description: 3/4 x 1/2 Flint
Cu.Ft./Bag: 1
Wt./Cu.Ft.*: 100 lbs.
Bags/Pallet: 20
Weight/Pallet: 2050 lbs.
Pallet Dim: 42″x40″x28″

Part No. A8076
Description: 1 x 3/4 Flint
Cu.Ft./Bag: 1
Wt./Cu.Ft.*: 100 lbs.
Bags/Pallet: 20
Weight/Pallet: 2050 lbs.
Pallet Dim: 42″x40″x28″

(back to top)

STANDARDS
Drinking Water Treatment System Components Classified by Underwriters Laboratories Inc.® in Accordance with Standard ANSI/NSF 61-(1991)-57Y3.

(back to top)

Filter Sand and Gravel are more fine media from Clack Corporation.
